Melcom Electronics Ltd products

Psat: 10 W, PAE: 40 %, LSG: 12 dB, S21: 19 dB, S11: -11 dB, S22: -8 dB, CW operation, Small 5 x 5 mm footprint.

> 30 dB Typical Small Signal Gain, 35 W Typical PSAT, Operation up to 22 V, High Breakdown Voltage, High Temperature Operation, Size 0.157 x 0.239 x 0.003 inches

Low Noise Amplifier/Driver Amplifier designed for high data-rate applications. Designed to operate over the band 17-31.5 GHz. 20 dB of linear gain, 2.6 dB noise figure. 2.5 x 2.5 QFN package, single positive bias (3.3 V). Well suited to demanding, high-order modulation schemes such as VSAT, ISM 24 GHz and millimetre wave 5G. Demo Board available.

37—59 GHz Low Noise Amplifier, 2.5 dB Noise Figure (LNA Bias) @ 50 GHz, 26.5 dB Gain, 19 dBm Saturated Output Power (Driver Bias), > 10 dB Input and Output Return Loss, 2 V, 55 mA for LNA Bias, 4V, 80 mA for Driver Bias
