Drag Finishing Machines - Brochure

www.rosler.comDrag Finishing Processwww.rosler.com Rösler® Drag Finishing Process Our system combines functionality with innovative equipment design which allows easy entry into professional drag finishing technology Highlights: ??Powerful drive unit with two separately adjustable drive systems ??Ergonomic machine operation with front loading and touchscreen controls ??Consistent component quality due to constant process parameters ??Permanent homogeneous media mixture due to effective media classification screen ??Customized solutions available: - basic model includes manually changeable process bowl - advanced model includes multiple process bowls that automatically shuttle based on the current process step Oberflächentechnik GmbH Vorstadt 1 D-96190 Untermerzbach Tel.: +49 95 33/9 24-0 Fax: +49 95 33/9 24-3 00 Info@rosler.com www.rosler.com Publ.-Nr. GB.250.05 - Specifications are subject to change without notice Suitable for the following finishing processes: Surface grinding, de-burring, edge breaking and radiusing, surface smoothing, high gloss polish-ing (wet/dry) R 4/700 SF R 6/1000 SF R 4/1300 SF Work bowl Ø (mm) 700 1000 1300 Work bowl height max. (mm) 450 500 695 Work bowl volume (l) 150 350 530 Number of work stations (pcs) 4 6 4 Space requirement (l x w x h in m) 1,3 x 1,5 x 2,6 1,6 x 1,9 x 2,75 2,34 x 3,2 x 3,25 Technical data: R 4/1300.3 SF Multi stage process for huge amounts of components with one single system Surface grinding, surface smoothing, polishing – all without having to remove and re-attach the components Examples of applications: ??Orthopedic implants (knee and hip joints) ??Tablet punches, plunges ??Dental implants ??Various gears and pinions ??Tool clamping systems, tool holders ??Milling tools (finishing of cutting edge and chip flute treatment) ??Engine components (cams, connecting rods, pistons, valves) ??Ball valves ??Parts for aerospace turbines ??Tool and die applications ??Decorative parts Process development and equipment from a single source: Media, compound and effluent treatment – from a single source. We can develop special media compositions to fit your unique finishing application. R 4/700.2 SF Customized 2-stage process in a system www.rosler.comRÖSLER Oberflächentechnik GmbH · www.rosler.comFAZAD D GBE I NLCH USA BRDUSAFICHGBENLBARORUSBRZACNINDRÖSLER Oberflächentechnik GmbH · Werk Memmelsdorf Vorstadt 1 · D-96190 Untermerzbach Tel.: +49/9533/924-0 · Fax: +49/9533/924-300 · rosler-de@rosler.com RÖSLER Oberflächentechnik GmbH · Werk Hausen Hausen 1 · D-96231 Bad Staffelstein Tel.: +49/9533/924-0 · Fax: +49/9533/924-300 · rosler-de@rosler.com RÖSLER Metal Finishing USA, L.L.C. 1551 Denso Road · USA-Battle Creek · MI 49037 Tel.: +1/269/4413000 · Fax: +1/269/4413001 · rosler-us@rosler.comRÖSLER France Z.I. de la Fontaine d’Azon · B.P. 513 – St. Clément · F-89105 Sens Cedex Tel.: +33/3/86647979 · Fax: +33/3/86655194 · rosler-fr@rosler.comRÖSLER Italiana S.r.l. Via E. Vittorini 10/12 · I-20049 Concorezzo (MI) Tel.: +39/039/611521 · Fax: +39/039/6115232 · info-it@rosler.comRÖSLER Schweiz AG Staffelbachstraße 189 · Postfach 81 · CH-5054 Kirchleerau Tel.: +41/62/7385500 · Fax: +41/62/7385580 · rosler-ch@rosler.com RÖSLER UK Unity Grove, School Lane · Knowsley Business Park · GB-Prescot, Merseyside L34 9GT Tel.: +44/151/4820444 · Fax: +44/151/4824400 · rosler-uk@rosler.comRÖSLER International GmbH & Co. KG Sucursal en España · Polg. Ind. Cova Solera C/Roma, 7 · E-08191 Rubí (Barcelona) Tel.: +34/93/5885585 · Fax: +34/93/5883209 · rosler-es@rosler.com RÖSLER Benelux B.V. Reggestraat 18 · NL-5347 JG Oss · Postbus 829 · NL-5340 AV Oss Tel.: +31/412/646600 · Fax: +31/412/646046 · rosler-nl@rosler.comRÖSLER Benelux B.V. Avenue de Ramelot 6 · Zoning Industriel · B-1480 Tubize (Saintes) Tel.: +32/2/3610200 · Fax: +32/2/3612831 · rosler-be@rosler.comRÖSLER Oberflächentechnik GmbH Hetmanekgasse 15 · A-1230 Wien Tel.: +43/1/6985180-0 · Fax: +43/1/6985182 · rosler-at@rosler.com RÖSLER Romania SRL Str. Horia Closca si Crisan 17-19 · RO -075100 Otopeni/ILFOV Tel.: +40/21/352 4416 · Fax: +40/21/352 4935 · rosler-ro@rosler.comRÖSLER Russland 40 Bolshaya Semenovskaya Str., bldg. 1, office 413 · 107023 Moscow Tel. / Fax: +7 / 495 / 665 63 32 · Mob.: +7 / 495 / 505 23 15 · rosler-ru@rosler.comRÖSLER do Brasil LTDA Estrada dos Galdinos 35 · Jd. Barbacena · 06700-000 - Cotia · São Paulo - Brasil Tel.: +55/11/46123844 · Fax: +55/11/46123845 · rosler-br@rosler.comRÖSLER S.A. Surface Technologies P.O. Box 7949 · 66 Regency Drive · Route 21 Corporate Park · Irene Ext. 31 · ZA-0046 Centurion Tel.: +27/12/345 2215 · Fax: +27/12/345 3731 · rosler-za@rosler.comRÖSLER – BEIJING Office 11N, Tower A, Beijing Fu Hua Mansion · No. 8, Chaoyangmen North Avenue Dong Cheng District · Beijing 100027 P.R. China Tel.: +86/10/6554 73 86 · +86/10/6554 73 89 · Fax: +w86/10/6554 73 87 · rosler-cn@rosler.comRÖSLER SurfaceTech Pvt. Ltd. No.9, I Main Road, M.L.A Layout · R.T. Nagar · IND-Bangalore 560 032 Tel.: +91/80 23534445 · Fax: +91/80 23339165 · rosler-in@rosler.comSurface Finishing · Shot Blasting · Engineering · Environmental TechniquesPubl.-Nr. GB.250.05 – Specifications are subject to change without notice• and more than 60 representations worldwide
