Model 200 Brochure

Heated Methane / NonMethane / Total Hydrocarbon Analyzer (NMHC) Model-200The VIG Industries, Inc. Model-200 is a microprocessor based, oven heated methane / nonmethane / total hydrocarbon gas analyzer designed for high accuracy, sensitivity and stability. The Model-200 uses two independent flame ionization detectors (FIDs), one to measure total hydrocarbons and the second coupled with a GC Column for the separation of the methane and nonmethane components. A sample is fed to the analyzer via an internal heated pump to the first FID for a real time total hydrocarbon reading. A portion of the sample is trapped and pushed through a column to separate the methane component and then to the second FID. Any remaining sample in the column is back flushed through the column to obtain the nonmethane component. All components that come in contact with the sample through analysis are maintained in a temperature-controlled oven to prevent condensation, and to provide repeatable, reliable performance in the analysis of a wide variety of hydrocarbon concentrations in gaseous mixtures or in ambient air.Features• Easy to use software• Automatic start-up/ignition• Heated sample pump heads• Two stage sample filter with exchangeable sintered stainless steel elements• Teflon isolated detectors (FIDs)• Automatic fuel shut-off system• Automatic flame-out indicators• Adjustable alarm and oven settings• Precision 1% of full scale• 19" rack/bench mountOptions• 4-20mA output - no extra charge• Zero and calibration solenoids with software• RS-232 interface• Internal combustion air supply Applications• Compliance Monitoring - U.S. E.P.A. Method 18 and Method 25A• Process Monitoring - Continuous monitoring and alarm or control of: process gas streams utilizing organic solvents, crude oil, and other chemicals containing hydrocarbons.• Efficiency Monitoring - Monitoring effluent of volatile organic compound (VOC) reduction equipment for environmental compliance, efficiency control of incinerators (Thermal or catalytic), scrubbers, carbon absorbers, and other abatement equipment, monitoring of catalytic converters, combustion and diesel engine efficiency.• Safety Monitoring - Lower explosive limit (LEL) monitoring and/or control of ovens/dryers, fugitive emissions monitoring, personnel work area monitoring, leak detection of process equipment or solvent storage areas.• Stack MonitoringRelated Available Equipment• Zero air generator (Reduces bottles)• Hydrogen generator (Reduces bottles)• Heated sample lines and controllers• Strip chart recorders and data loggers• NEMA rated enclosuresVIG INDUSTRIES, INC. 4051 E. La Palma #C Anaheim, CA 92807 • Toll Free (800)862-7844 • Phone (714)632-8200 • Fax (714)632-8201• http://www.vigindustries.com
