IntegriTech -Model CS-SMP-26 -26 Inch HD LED Medical Display
The Clarity Surgical 26" HD Display has the latest technology needed to reproduce high-resolution HD images. The front filter bonding process provides higher brightness, higher contrast ratio, minimized glare, resistance to internal condensation, and increased strength. Video connections are available for DVI-D, SDI (SD/HD/3G-SDI), VGA, and Component, which supports compatibility with popular video formats utilized in Operating Room applications.
Designed for a Better Image
Our 26 inch medical grade display has the latest technology needed to reproduce super-sharp HD images. The front filter bonding process provides higher brightness, higher contrast ratio, minimized glare, resistance to internal condensation, and increased strength. Flush-front glass with touch interface control is with touch interface control is easy to clean and allows for fast procedure turnaround. CSSMP-26 has an ingress protection (IP) rating of 33 to safeguard the display monitor’s internal components and protect against the intrusion of solids or liquids.
Broad Compatibility
Thanks to rapid signal detection and robust mode tables, CS-SMP-26 automatically recognizes other highly specialized surgical and diagnostic equipment found in surgical suites, operating rooms, emergency rooms, and procedural facilities.
Video connections are available for DVI-D, SDI (SD/HD/3G- SDI), VGA, C-Video, S-Video, and Component. This ensures compatibility with popular signal types found in surgical applications.
User Friendly
CS-SMP-26 features an intuitive, full- featured on screen menu for image and layout settings. Multi-modality options let doctors view two images at the same time. The rounded monitor housing corners help protect OR personnel from accidental bumping injuries. Its lightweight design is ideal for boom or spring-arm mounting, and the convenient back cable cover helps organize and manage multiple cords.
