dBMEDx -3D Scan Head Core Technology

• Automatically locates bladder without aiming
• Automatically detects male/female anatomy
• Provides results you can trust
• Wireless design simplifies decontamination protocols
• No annual calibration required

The patented (US #8,206,307), 3D scan head design places an array of transducers onto a spinning core that supports the electronics subsystem, battery, wireless radio and motor. As a result, the palm-sized device houses the entire ultrasound machine including image processor, power supply and wireless interface – a remarkable miniaturization effort.

This architecture allows the scan head to collect multiple b-mode slices resulting in a true 3D data set. It is this 3D data set that is the key to enabling the automated calculation of the volume of the bladder. It is the same game-changing, rugged design that is the key to our automated self-calibrating methodology.
