TPS - Adult Human Torso Phantom for R&D
Adult Human Torso for R&D is a realistic medical imaging phantom that can be customized both internally & externally to suit any research application. It can be designed and produced to be compatible with Ultrasound, X-RAY, CT, and MRI.
Adult Human Torso for R&D is a realistic medical imaging phantom that can be customized both internally & externally to suit any research application. The product can be designed to match the specific requirements of any research project and can be made to be compatible with Ultrasound, X-RAY, CT, and MRI.
Base model includes:
- Bones included:
- Complete Spine
- Complete Ribcage
- Pelvis
- Femur
- Thoracic organs included:
- Trachea
- Anatomically correct Heart
- Lungs
- Major abdominal organs included:
- Stomach
- Liver
- Kidneys
- Bladder
- Large & small intestines
Optional organs (available upon request):
- Diaphragm
- Spleen
- Pancreas
- Esophagus tube
- Psoas Major
- Colon
- Muscles
- Vasculature
Optional features (available upon request):
- Internal hemorrhages at bilateral chambers, pelvic area, pericardial area, perisplenic areas etc.
- Lesions and tumors at precise locations.
- Customizing the phantom with motion or bleeding.
Soft tissue and organs: Composition of urethane base soft resin
Synthetic bones: Patented ceramic-reinforced epoxy-based composite material (optional)
Dimensions and Weight of the Phantom:Size: 85 x 46 x 26 cm(approx.) Weight: 40 Kgs (approx.).
Dimensions and Weight of the Shipment:- Without hard carry case: Size: 91 x 60 x 30 cm (approx.) Weight: 45 kgs (approx.)
- With Hard carry case: Size: 120 x 65 x 45 cm (approx.) Weight: 65 kgs (approx.)
- Male Standard Torso
- Design video
- Manual
- Hard carry case (optional)
