ACME - Model BPG 8000 - Atrial Fibrillation, Blood Pressure Monitor
Our BPG 8000 is an automatic blood pressure monitor with AFib Detection. This device accurately detects in real-time irregular heart rhythm from Atrial Fibrillation with our proprietary PPG (photoplethysmogram) technology. Our BPG 8000 can measure both blood pressure and atrial fibrillation at the same time. Within 30 seconds, you will have your results! It`s so easy to use that you can use this device at home. Monitor your heart`s activity with our optical module. By shining light onto your skin, it can gather information using our proprietary algorithm.
Photoplethysmogram (PPG) is an optically obtained plethysmogram, a volumetric measurement of an organ. The change in volume caused by the pressure pulse is detected by illuminating the skin with the light from a light-emitting diode (LED) and then measuring the amount of light transmitted to a photodiode.
In just a few steps, you can begin measuring systolic blood pressure, diastolic blood pressure, and heart rate.
There are several reasons why we focus on atrial fibrillation:
- The risk of stroke is five times higher in people with AF.
- AF nearly doubles the death rate from stroke.
- 3 out of 4 AF-related strokes can be prevented.
- 70% of AF patients who have stroke will die as a result.
- An estimated 2.2 million people are diagnosed with AF, but it is estimated that 1/3 of Americans who have it are undiagnosed.
- The number of adults developing AF increases with age.
With AF, your heart is not pumping like it should. The slow-moving blood can pool inside, which makes it easier for clots to form. If a clot travels through the blood stream to your brain and lodges, you could have a stroke.
We would like to prevent his. As a result, with proven clinical studies, our product can help accurately detect AF right from the comfort of your home!
Measurement Method: Oscillometric
Measurement Range: Pressure: 0 ~ 300 mmHg
Pulse: 40 ~ 199 Beats / Minute
Accuracy: Pressure: ± 3 mmHg
Pulse: ± 5 % Max
Inflation: Automatic Inflation (Air Pump)
Deflation: Automatic Air Release Control Valve
Display: Liquid Crystal Display
Memory: 120 Total Records for 3 Users
Unit Dimensions: 3.94" (L) x 5.51" (W) x 2.32" (H)
Unit Weight: 320g ± 5g (Cuff and batteries excluded)
Cuff Size: Approximately 9 ~ 13"
Storage / Transporation Environment: Temperature: -25°C ~ 70°C (-13°F ~ 158°F)
Humidty: ≤ 93% R.H.
Operation Environment: Temperature: 5°C ~ 40°C (41°F ~ 104°F)
Humidty: 15% ~ 93% R.H.
Atmospheric Pressure: 700hPa ~ 1060hPa
Power Supply: 1. AAA "LR03" (1.5V) Alkaline Battery x4
2. 6V 1A AC/DC Adapter (Optional)
Battery Life: Approximately 200 measurements
Product Life: 5 Years (4 times per day)
Sleeping Mode: Without any operation for 1.5 minutes, device will automatically shut off.
Accessories: 4 AAA (LR03) Alkaline Batteries, Arm Cuff with Tube, Instruction Manual, and Storage Pouch
