Mcube -Model BioCon-700 -Bladder Volume Measurement System
CUBEscan™ BioCon-700 is a portable ultrasound device intended to measure the urine volume in patient’s bladder. BioCon-700 transmits ultrasound signals into the abdomen of a patient and receives the echoed signals. Using the echoed signals, the system determines the bladder’s outline and calculates the bladder volume based on the outline. A user can measure bladder volume quickly, easily and non-invasively with BioCon-700.
Display: 7 inch TFT-LCD color touch screen
WVGA (800 x 480 pixels), 16.7 million colors
Bladder output range: Bladder volume range : 0 – 999ml
Accuracy : ±15%, ±15ml (0 – 999ml)
Ultrasound probe: Ultrasound frequency : 2.6MHz
Scan angle : 120º
Penetration depth : 18cm (Normal patient)
Power:
Rechargeable Li-ion battery
3.33A, 9V DC adaptor (Input : AC 100-240V, 50-60Hz)
Charging : Approximately 6 hours
External interface: USB 2.0 basic
Printer: Built-in thermal printer (57mm width)
External memory: 2G SD card
Dimension: 66 x 260 x 130mm (1.45kg)
- Helps make a diagnosis of LUTS(Lower Urinary Tract Symptoms) by using urine volume or PVR(Post-Void Residual)
- Monitoring of POUR(Post-Operative Urinary Uretention) or Post-operative dysuresia
- Helps make a decision when to catheterize patient who may have urinary retention
- Prevents UTI(Urinary Tract Infection) by reducing unnecessary catheterization
- Monitoring of Anti-cholinergic drug side effect and prescribing drug dosage
- Supports to train urination and self-catheterization as an assistance tool
