EICMED - Model Transfusio-Therm 3000 - Blood and Plasma Thawing Devices
FromEICMED GmbH
The blood bottles are heated by high frequency. The device is designed to accommodate 3 units of blood. The temperature is constantly monitored during heating. When the target temperature is reached, there is an optical and acoustic signal.
Most popular related searches
The device can be used to thaw and heat FFP (blood plasma) and EK (erythrocyte concentrates) up to a maximum bag size of 600ml. In order to ensure homogeneous heating, the three units of blood are mixed during the process.
If errors or deviations in the process are detected by the safety- and protection systems, these are also displayed on the control unit and signaled acoustically.
An easy-to-understand operating concept is the basis for high process reliability.
- Blood and erythrocyte concentrates
- Fresh Frozen Plasma (FFP)
- FFP and EK preserves can be used quickly
- Short thawing time for three bottles of blood
- Reliable process due to 2-fold temperature monitoring
- Dry heating
- No warm-up time
- No consumables
- Easy handling
- Voltage: 230 V
- Power frequency: 50 Hz
- Fuse: 10 AT
- Type of heating: Microwave 2.450 MHz
- Set temperature: 30°C+/- 4°C; 37°C +1°/-4°C
- MDR-classification: Class I
- Dimensions: 460mm x 680mm x 540mm
- Weight: 70kg
