Diconex -Model InCCA Bit -Clinical Chemistry Autoanalyzer for Medium-Volume Laboratories
FromDiconex SA
InCCA Bit is a random access clinical chemistry autoanalyzer for small volume laboratories; this analyzer will ensure the requirements of an affordable automated system. It is an open system, utilizes PMMA washable and reusable cuvettes, with friendly software interface. Lowest water consumption, ideal start your laboratory automatization. Designed for veterinary laboratory, ideal for its size and features. Low maintenance units, having cycle counters for parts, they will be replaced under maintenance program when it should be replaced, 100% cost-effective.
Most popular related searches
GENERAL
- Average throughput: 300 tests/hour – 500 test/hour with ISE
- Random access, automated, discrete
- Open system
SOFTWARE
- Stats, samples, calibrators and controls loading at any time in the process
- Unlimited number of methods in memory
- Calibration curves and reaction curves
- Automatic re-dilution and repetition
- Reaction graph
- Preventive maintenance alarms
- Levy – Jennings plots
- LIS
- Reagent inventory check
- QC graphics
- Settings for DOA and TDM test
- Linux and Windows compatible
- Analyzer testing
- Reagent statistics consumption
OPTIC SYSTEM
- Double beam
- 10 Interferential filters: 340, 380, 405, 450, 505, 546, 578, 600, 650, 700 nm (up to 11)
- Long life kripton halogen lamp
- Optical path: 6 mm
- Photometric range: -0.100 to 3.600 A
- Measurement type: monochromatic and bichromatic
- Direct reading
HYDRAULIC SYSTEM
- High resolution dilutor
- Minimun sample volume: 2 µl
- Minimun reading volume: 220 µl
SAMPLE AND REAGENT PIPETING SYSTEM
- Preheated probe with additional mixer integrated
- Internal and external probe washing
- Conductive probe level sensor
- Impact sensor (vertical & horizontal)
METHODS
- Colorimetric
- Turbidimetric
- Kinetics
- Ion selective electrode
POWER REQUIREMENTS
- 100/240 VAC | 50/60 Hz
DIMENSIONS
- Width 80 cm x Height 45 cm x Depth 58 cm
- Weigth: 50 Kg
SAMPLE AND REAGENT TRAY
- 60 cooled reagent tray positions
- 60 sample positions
- Continuous sample loading
- Primary tubes
CUVETTE TRAY
- 100 washable and reusable PMMA extra longlife reaction cuvettes
- Warm air bath
- Working temperature: 37º C (Variable from room T +/- 5ºC to 45ºC)
CUVETTE WASHER
- Fully Automatic
OPTIONAL
- Sample bar - code reader
- Extra filter: any wavelength
- ISE module (Na+, K+, Cl-, Li+)
