DSE Clinical - Model E50 Life - Dental Simulation Units
Being designed on the basis of the KaVo ESTETICA E50 Life, it meets the state-of-the-art standards - especially in terms of ergonomics, operability, hygiene and reliability. The modular concept of the DSE Clinical E50 Life provides a high degree of flexibility. The unit allows for optimal adaptation to the individual requirements, demands and spatial conditions of each clinic.
- New standards in hygiene, treatment ergonomics and ease of use.
- The students are already training with the original components of a treatment unit in the pre-clinical phase and do not have to change their acquired workflows later on.
- Perfect ergonomic preconditions for every treatment concept.
- Optimum treatment ergonomics due to height-adjustable doctor and assistant element.
- Highest health protection for students through automated intensive germ reduction.
- There are further options available: e.g. endo function, intraoral camera for comfortable working without disruptive auxiliary devices.
Even in the pre-clinical phase, they learn to use the original components of a treatment unit with confidence and in a routine manner. Later on, they don`t have to adapt to new workflows in their day-to-day work.
You can configure the DSE Clinical E50 Life with the appropriate dentist element depending on the treatment concept
The dentist element can be re-positioned at any time. This way you always have everything within reach. Sitting or standing. Alone or with assistance.
The operation of both dentist elements with their self-explanatory interface and direct selection keys is intuitive and does not use any double assignment. When you remove an instrument, all essential information is immediately displayed in a clear and concise manner. MEMOdent also allows you to recall stored parameters for each instrument for recurring treatment procedures.
This function is available for up to six practitioners and three user levels. If desired, you can retrofit an optional instrument tray with five or six holders. The same applies to the endo and multimedia functions as well as many other modules such as camera, scaler or polymerisation light.
Your assistant has everything at handThe optional assistant element offers space for the spray mist suction device, the saliva extractor, the second triple-function handpiece and the LED polymerisation handpiece. For optimal treatment ergonomics, the height adjustment is also available as an option (adjustment range: 30cm).
A considered and intuitive design on the control membrane, with direct selection, buttons facilitates the control of the following functions:
- Intensive germ reduction,
- Light dimmer,
- Timer and position adjustment of the patient simulator.
The direct selection buttons enable an intuitive, efficient treatment procedure - all major functions can be activated at the push of a button.
In narrow workspaces or when operating with two hands, the assistant element can be replaced with a compact suction hose holder. It offers holders for the spray mist suction and saliva extractor and can be adjusted in five positions.
The DSE Clinical E50 Life is configured as standard with the connection to the compressed air supply and is equipped with the plugs and supply voltages required at the installation location.
Space requirement
- Width approx. 486 mm
- Depth approx. 250 mm
- Maximum height 2300 mm
- Weight approx. 70 kg
- Nominal voltage 230 V / 50/60 Hz
- Power input 800 VA
- Mains fuse T6.3 H / 250 V
- Maximum permitted mains voltage fluctuations ±10% of the nominal voltage
- Overvoltage category II
- On-site protection MCB C 16 A or screw-type fuse 10 A
- Drinking water quality
- Water hardness 1.5 to 2.14 mmol/l; 8.4 to 12 °dH
- On-site water filtration 80 µm
- pH 7.2 to 7.8
- On-site water pressure 2 to 6 bar
- Maximum water consumption 4 l/min
- Air inlet pressure 5.2 to 7 bar
- Maximum air consumption with external suction 60 l/min
- In case of higher water hardness (over 12 °dH), a water softening system using the ion exchange method must be installed. Water that is too soft (below 8.4 °dH) can promote algae formation.
Environmental conditions
- Operating environment / temperature 5 to 40 °C
- Relative humidity 30 to 75%, non-condensing
- Pollution degree 2
- Maximum installation altitude 2000 m MSL
Operating mode
- Intermittent duty for motor K 200/motor KL 703
Operating time is 2 minutes; pause time is 8 minutes - Intermittent duty for motor KL 702
Operating time is 0.5 minutes; pause time is 9 minutes - Intermittent duty for lifting motor simulator
Operating time is 0.5 minutes; pause time is 7 minutes
Dental drive speeds
- Instruments depending on type up to 300,000 rpm
- KL motor 40,000 rpm
Ergonomics is a matter of choice: Individual adjustment of the DSE Clinical E50 Life
Patient simulator
- Vertical height adjustment 680-1000 mm from incisal edge.
- Inclination of backrest and headrest (-10°/+85°), head movement (25° forward, 40° backward, 20° right-left).
- Additional horizontal swivel for more treatment freedom under narrow installation conditions (45° left-right).
- The patient simulator can be equipped with all KaVo jaw simulators (G20, G40 and G50) and tooth models according to customer specifications. Various facial masks with or without drainage are available as options.
- The patient simulator can be adjusted quickly and safely either pneumatically or electrically as on the treatment unit. The electrical adjustment also offers the possibility to store several user-definable positions.
