ERBA -Model ECL 760 -Fully Automated Coagulation Analyser
The ECL 760 is an advertising display system designed to provide dynamic and engaging visual presentations. Offering high-resolution output, the ECL 760 is suitable for a range of advertising applications, from retail environments to events and exhibitions. The system supports various multimedia formats and is equipped with features that allow for easy content management and scheduling. Its robust design ensures reliable operation in different settings, while its modular architecture allows for integration with other display systems. The ECL 760 also supports remote management capabilities, enabling users to update and control content from a central location. This makes it an efficient solution for companies looking to enhance their advertising capabilities with flexible, high-impact displays.
Advanced random access system for clotting, immunologic and chromogenic assays for routine and STAT testing
- Simple, desktop analyser
- Bi-directional LIS communication
- Barcode reader for sample identification
- 60 PT tests / hour
- Colour touch screen and the possibility to connect an external keyboard, a mouse and a printer
- 7 measuring channels
- 8 incubation positions at 37°C +/- 0.2°C for reaction cuvettes
- 23 refrigerated and stir able positions for reagents, diluents and cleaner
- 27 positions for samples, primary tubes, vacuum system tubes and cups
- 72 positions for reaction cuvettes
- Pipetting needle with automatic preheating, collision protection, liquid level detection of and control of reagent volumes
- Volume of reaction liquid: 150-300 µl, pipetting volume: 4-200 µl
- Parameters: PT, APTT, TT, Fibrinogen, Coag. factors, D-Dimer, ATIII, Protein C, Protein S, Lupus Anticoagulans
- Built-in thermal printer
- RFID for security of use
- Quality Control: 12 QC user defined QC material
- Calibration: Automatic, manual, 6 point calibrations
- Storage capacity of more than 10 000 data curves
- program with automatic Levey-Jennings graph monitors system performance
- Comprehensive Erba Haemostasis reagent line
- Universal power supply 100-240V~50/60Hz
- dimensions: 650 x 580 x 510 mm
- weight: 53 kg
- 2 USB ports
