WOER - Model AMS - Heat Shrinkable Marker Sleeves for Identification
The AMS-M heat shrinkable marker sleeve is crafted from radiation cross-linked polyolefin material, known for its durability and flame retardancy. Designed mainly for the identification of wires and cables, this sleeve finds applications in diverse sectors like military, defense, aerospace, and marine industries. The sleeves adhere to technical standards such as AMS-DTL-23053/5 Class 1&3, SAE-AS 81531, MIL-STD-202F/Method 215J, UL224, and RoHS compliance, ensuring quality and reliability. Available in shrink ratios of 2X and 3X, these sleeves offer versatile use in various environmental conditions. WOER, a manufacturer with extensive experience, caters to industries requiring heat shrink tubing for purposes including electrical insulation, cable identification, and component protection. WOER also provides value-added services like custom cutting, printing, and packaging, enhancing usability and efficiency.
AMS-M heat shrinkable marker sleeve is designed to satisfy the needs of permanent wire and cable identification. This wire marker sleeve is made from radiation cross-linked heat shrinkable polyolefin, ensuring high durability and flame retardancy. It can be widely used in military, defense, aerospace, marine and other industries. Our standard AMS-M heat shrinkable marker sleeve meets the requirements of AMS-DTL-23053/5 Class 1 &3, SAE-AS 81531, MIL-STD-202F/Method 215J, UL224, and RoHS.
- Material: fabricated from irradiated, thermally stabilized, flame retarded, modified polyolefin compound
- Application: military, defense, aerospace, marine, etc.
- Operating temperature range: -55℃～+135℃
- Minimum recovery temperature: +85℃
- Maximum storage temperature: +50℃
- Shrink ratio: 2:1, 3:1
- Color: white, yellow, other colors are available upon request
- Printing: single sided printing or double sided printing
- Supplied format: ladder-style or continuous sleeve
- Recommended printer: thermal transfer printer or laser printer
- Recommended ribbon: N85 resin ribbon, black, 100mm(width)×300m(length)
