Intravascular Imaging System
First and only intravascular imaging system to combine co-registered IVUS and OCT on a single system. The Novasight Hybrid System provides versatility with all the benefits of each modality (image quality, system size, deliverability) with no significant tradeoffs. Single-use IVUS OCT catheters and a single console allow hospitals to save by purchasing and maintaining one console instead of two. A single console frees up cath lab space and makes equipment selection for procedures easier.
Most popular related searches
intravascular imaging system
intravascular image
intravenous imaging
hybridization system
guiding catheter
catheter
catheter single
imaging catheter
Fast pullbacks, fast longitudinal reconstructions
IVUS OCT pullback speeds up to 25mm/s (100fps), allowing for faster IVUS image acquisition than other IVUS systems.
Rapid longitudinal reconstructions post-pullback, allowing for immediate review of collected image frames.
Long insertable length
149cm insertable length for accessing distal lesions.
Short distal tip
Less than 12mm from the distal tip of the catheter to the imaging core, allowing for imaging very close to lesions.
Customizable pullback lengths
User-defined pullback start and end positions, allowing for pullbacks that are only as long as necessary to capture the images needed.
6F guide catheter and 0.014" guidewire compatible.
149cm working length.
1.7F entry profile.
Radiopaque markers:
- 3mm from distal tip
- 10mm from distal tip
- Imaging head (11.5mm - 111.5mm from distal tip)
IVUS + OCT Pullbacks:
Speeds:
10mm/s @ 100fps (slice thickness: 100 microns)
25mm/s @100fps (slice thickness: 250 microns)
Length:
Customizable from 0-100mm
IVUS-only Pullbacks:
Speeds:
0.5mm/s @ 30fps (slice thickness: 17 microns)
1mm/s @ 30fps (slice thickness: 33 microns)
5mm/s @ 100fps (slice thickness: 50 microns)
Length:
Customizable from 0-100mm
