Tecme - Medical Air Compressor
FromTecme
The Neumovent Air Compressor provides clean and dry compressed air for medical ventilators. It can be used as a primary source of air or as an automatic backup system, in case of a failure of the main source of air in the medical facility. The Neumovent Air Compressor is available for use with all Neumovent Ventilators: Advance, Neo and Ts. Also, it’s available the Compressor Trolley making a fully integrated system.
Most popular related searches
medical air compression
medical air
medical ventilation
medical ventilator
healthcare facility
depression
medical compressor
- Nominal voltage and frequency (*) : 230 V/50Hz - 115 V/60 Hz
- Compressor efficiency : 50 l.min–1/ 3,5bar
- Peak flow : 200 l.min–1
- Air tank capacity : 2 lit
- Filtration of air to : 5 μm
- Dew point depression at 3 bar, 20°C : 5°C under the ambient temperature
- Dew point depression at 3 bar, 20°C, with membrane dryer. : 10°C under the ambient temperature
- Outlet connection : DISS 1160-A (3/4“-16 UNF)
- Operation mode : Continuous - S1
- Wall connection : yes
- Classification according to MDD93/42/EEC,2007/47/EC : class II.b
- Noise level : ≤ 50 dB [A]
- Dimensions(wxdxh)(**) : 445x355x440mm
- Weight (**) : 34 kg
