E-Grind - Metal Bond Mesh Diamond Powder

Metal Bond Mesh Diamond: EA-M19

• Medium toughness, Irregular shape,
• new cutting edges always occur during the grinding process. The texture surface offers good bond combining ability.
• For resin bond and Vitrified bond system
• Available Sizes: 60/70 through 500/600
• It is also available in Ni coating

Metal Bond Mesh Diamond: EA-M20

• Medium Toughness, Rough and Irregular crystal,
• Similar to EA-M19, but more durable.
• For resin bond and Vitrified bond system
• Available sizes: 80/100 through 500/600
• It is also available in Ni coating

Metal Bond Mesh Diamond: EA-M35

• Medium-High Toughness, Angular shape.
• Excellent free cutting ability and more durable than EA-M40.
• For resin bond and Vitrified bond system
• Available sizes: 30/40 through 120/140.
• It is also available in Ni coating

Metal Bond Mesh Diamond: EA-M40

• Medium toughness, Angle crystal, Friable.
• Excellent free cutting ability.
• For Resin bond, Electroplated and Vitrified bond system.
• Available Sizes: 30/40 through 500/600
• It is also available in Ni coating

Metal Bond Mesh Diamond: EA-M45

• High Toughness, Semi-blocky
• It combines the long using life and high working efficiency.
• For Resin Bond system, Vitrified bond system, Electroplated tools.
• Available Sizes: 40/50 through 500/600
• It is also available in Ni coating and Ti coating.

Metal Bond Mesh Diamond: EA-M50

• High Toughness, Blocky
• Durable provides the shining surface on the workpiece.
• For Resin Bond system, Vitrified bond system, Electroplated tools.
• Available Sizes: 40/50 through 500/600
• It is also available in Ni coating and Ti coating.
