BTBP -Mini Clarity 2D & 3D Research Single Camera system
The Mini 2D & 3D Research System is a portable yet powerful 2D and 3D clinical research system, that provides users with a comprehensive set of measurements. It is capable of 2D measurements and 3D topography of skin features as well as 3D facial contour measurements. Users have the ability to create highly configurable studies and recipes, all in a system with a portable form factor.
Most popular related searches
- Detailed, high resolution 3D models & measurements
- Facial contour and volume modeling
- Multi-spectral imaging to view & measure surface and sub-surface features
- Automatic detection of over 50 facial regions for use in analysis
- Automatic alignment of all images and 3D models
- Archiving & retrieving
- Study management modules
- Batch Processing
- Movie timeline of skin progression *
- Progression trends*
- Image and 3D model export
- Data export into Excel
Power Specifications
- Input: 100 - 240 VAC 120 @ 5 amps
System Dimensions
- (l x b x h) : 12" x 19" x 14" inches
- Setup counter size : 16" x 18" inches
System Weight
- Lbs : 21.6 pounds
- Kgs : 9.8 kgs
Shipping Requirements
- Altitude: 0 to 39,370 feet (12,000 m)
Environmental Specifications
- Operation temperature : 22° ± 5°C non-condensing
- non-operating temperature: -40 to 50 °C non-condensing
- Relative humidity (Operating) : 10 to 70% RH, non-condensing
- Relative humidity (Non-Operating) : 5 to 93% RH, non-condensing
- Dark room : Yes
- No reflective objects in front of system : Yes
2D & 3D Facial Modeling & Measurement System
- Single Camera System
- 22 megapixel
- SLR image capture in 16-bit
