ClearLite POLY - Model BF05717-01 - P2 1310 11 NA Optical Fiber

Physical Characteristics

• Coating Material: PYROCOATR
• Cladding Diameter: 125 } 2 ƒÊm
• Coating/Buffer Diameter: 155 } 5 ƒÊm
• Core/Clad Offset: . 1.0 ƒÊm
• Core Diameter (Nominal): 8.4 ƒÊm
• Clad Non-Circularity: . 2.0%

Optical Characteristics

• Type: Single-Mode
• Operating Wavelength: 1310/1550 nm
• Cutoff Wavelength: . 1290 nm
• Mode Field Diameter @ 1310: 9.3 } 0.5 ƒÊm
• Mode Field Diameter @ 1550: 10.5 } 1.0 ƒÊm
• Attenuation @ 1310 nm: . 0.7 dB/km
• Attenuation @ 1550 nm: . 0.6 dB/km
• Numerical Aperture: 0.11

Mechanical and Environmental

• Operating Temperature: -65 to +300‹C
• Short-Term Bend Radius: . 10 mm
• Long-Term Bend Radius: . 17 mm
• Proof Test Level: 200 kpsi (1.38 GPa)
