Quickie - Model Q500 H - Rear-Wheel Drive Power Wheelchairs

SHARE

The QUICKIE Q500 H brings you a unique blend of rear-wheel drive and mid-wheel drive technology, delivering impressive outdoor performance coupled with indoor maneuverability. Bringing you the best of both worlds and exceptional comfort.

Most popular related searches
power wheelchair
wheelchair

Hybrid-wheel drive base

For the first time, QUICKIE brings you a unique blend of rear-wheel drive and mid-wheel drive technology, delivering impressive outdoor performance with indoor maneuverability and exceptional comfort. All Q500 H bases come with Occupied Transit tie-down brackets as standard, no charge.

QUICKIE Motor Technology

Our robust motor technology can`t be easily duplicated anywhere else. That`s because we`ve spent years working closely with our manufacturer to develop a longer-lasting, highly efficient motor with improved performance, drivability, and range.

Engineered for optimal driving performance
We know that more time is spent maneuvering around a home and workplace versus traveling long distances. That`s why we`ve designed our motors to give you the control you need in small spaces without sacrificing the power you want to tackle obstacles. Plus, you`ll be able to drive 10% further on the same battery capacity. Similar to a car driving on the highway versus in the city, don`t sacrifice performance in places where it`s needed the most.
Reduced thermal rollback
The larger fins found on our motors aren`t just a stylish design feature. Larger cooling fins enable heat to escape more effectively, reducing your risk of thermal rollback so you can drive 25% further and faster when combined with the additional boost, even when on an incline or faced with uneven surfaces.
Equipped with 10 seconds of power boost
Overcoming obstacles like steeper inclines and even door jambs gets easier with our controller and motor combination. These two systems work together to provide you with an additional 10 seconds of boost for that extra power whenever you need it.
Designed to last
Unlike some of our competitors, QUICKIE motors feature metal gears instead of plastic. Polished for low noise and high efficiency, our all-metal gears exceed expectations in tough conditions. We go the extra step in polishing those gears because we believe that a little extra effort goes a long way in creating a better ride.

QUICKIE Motor Technology continually exceeds rigorous testing standards. With a proven 99% success rate, your ride will be unlike any other. QUICKIE 4-pole motors generate 18% more power than previous generations.

Control at Your Fingertips

Control your environment with the Q500 H and its advanced controller technology. Available with the reliable VR2 control and the superior R-Net advanced joystick, the large, easy-to-read color display and simple-to-control paddle switches allow for intuitive operation.

CONNECT

Seamlessly take control of your environment using the integrated infrared functionality. Control your TV, docking stations, and other home entertainment systems easily via your joystick.

BLUETOOTH®

Control your phone, computer, tablet, and any other Bluetooth® devices, compatible with Android™ and Apple® iOS devices from your Q500 H power wheelchair with this useful optional extra. Connect and control up to four devices.

QUICKIE-PATENTED ASSIGNABLE BUTTONS

Change the function on any button on your joystick to any command you desire thanks to QUICKIE`s patented assignable buttons. You can also assign a second (long press) function to buttons for quicker, simpler, and smoother access to commonly used functions without having to use your joystick.

Dimensions
  • Product Width:24.5"
  • Product Length:36"
  • Seat Width:16" to 22"
  • Seat Depth:14" to 22"
Pre-Set Seat Frame Angle:
  • 0°
  • 3°
  • 6°
  • 9°
Seat-to-Floor Height:16.5" to 19"
Back Height:21" to 30"
Turning Radius:25.5"

(excludes footplates)

Ground Clearance:3"
Product Information
Model Number:EIPW32

HCPCS Code:No Power Seating Options
  • Group 3 Standard Duty - K0848
  • Group 3 Heavy Duty - K0850
  • Group 4 Standard Duty - K0868
Single Power Seating Options
  • Group 3 Standard Duty - K0856
  • Group 3 Heavy Duty - K0858
  • Group 4 Standard Duty - K0877

Multi Power Seating Options
  • Group 3 Standard Duty - K0861
  • Group 3 Heavy Duty - K0862
  • Group 4 Standard Duty - K0884
Starting Retail Price:$8,262
  • Warranty:Lifetime Limited
  • Performance/Weights
  • Max. Range:Up to 17.7 miles

    (w/Group 24 batteries)

Max. Speed:
  • 6 mph (standard)
  • 5 mph (optional)
  • 8 mph (optional)
Battery Size:
  • Group 24
  • Group 34
Drive Wheel Position:Rear
Suspension:6-wheel independent suspension
Wheel Options:Drive Wheels
  • 13"
  • 14"

Casters
  • Front: 9"
  • Rear: 4"
Transit:ISO 7176-19:2008 Transit Approved

User Weight Capacity:
  • 300 lbs.
  • HD: 350 lbs.
Product Weight:
  • NPC: starting at 343 lbs.
  • SPC: starting at 367 lbs.
  • MPC: starting at 381 lbs.
