Techno - Model ASUKA HTX-100 - Rice Bag Radiological Inspection Device

SHARE

Complying with the provisions of the Ministry of Health, Labour and Welfare Act `screening radioactive cesium in food`, our equipment measures the concentration of radioactive cesium per a rice bag (30kg), and determines the presence or absence of the exceedance reference value. Automatic continuous measurement and printing of the measurement results are possible with the style in a rice bag on a conveyor belt. Including bar code reading, measurement, printing of the measurement results, and transport, the inspection time per a rice bag is completed within 15 seconds.

Most popular related searches
radiology system
radiology
  • Calibration of energy is corresponding automatically each day before starting-up.
  • Reduced the size of the equipment by adopting the new detector that provides a low background.
  • Short measurement time and high measuring accuracy by expanding effective light receiving area.
  • Equipped with the safety, and the all measurement are automated.
  • Workable by one worker.
  • Equipped with a variety of software.
  • Automatic measurement of the measurement mode according to user requirements and local circumstances.
  • Achieve the temperature range from -10 ℃ to 45 ℃, by the heater use.
  • Up moisture-proof effect.
  • It can be applied to crops other than rice, for example, peach, green peppers, tomatoes, fish, etc.
  • Upon a request, handling transport to the measuring device can be automated.
  • Size : 1120(W) x 1300(D) x 1480(H) mm
  • Weight : about 2300kg
  • Compliance with laws and regulations : "Law of radioactive cesium in food screening" communicated from the Ministry of Health, Labour and Welfare.
  • Installation environment :
  • Operating temperature range: -10 ~ 40 ℃ (with heater)
  • Operating humidity range: below 80% (no condensation)
  • Background value: 1.0μSv / h (standard)
  • Measurement speed : 15 seconds (standard) / a bag (bag 30kg)
  • Detection limit : 5Bq/Kg (measurement 14 seconds)
  • Measurement lower limit : When the reference value is 100Bq/kg, 20Bq/kg (measurement 2 seconds).
  • [Calculated value based on the demonstration]
  • The other function : The display of the measurement result (touch panel), bercord, QR code printing.
  • Standard price : 20 million yen
