Sanitary Fittings include sanitary elbows, sanitary tees, sanitary cross, sanitary clamps, sanitary ferrules, sanitary adapters, sanitary reducers, sanitary flanges, sanitary end caps and sanitary pipe holders.
Sanitary butt-welded fittings are with butt-welded ends. They are widely used in pipeline systems for food, dairy, beverage, cosmetic, pharmaceutical, and fine chemical industries.Most popular related searches
cosmetic pharmaceutical
pharmaceutical chemical
pharmaceutical beverage
cosmetic chemical
pharmaceutical industry
|
SS2S-- 90° Buttweld Elbows w/tangent, Polish ID/OD |
||||||
| Tube OD (Size) |
A | Nominal (Wall) |
Part Number 304 |
Part Number 316L |
||
| 1/2" | 3.000 | 0.065 | SS2S7-0.5-316 | SS2S7-0.5-316 | ||
| 3/4" | 3.000 | 0.065 | SS2S7-0.75-316 | SS2S7-0.75-316 | ||
| 1" | 2.062 | 0.065 | SS2S7-1-304 | SS2S7-1-316 | ||
| 1.5" | 2.937 | 0.065 | SS2S7-1.5-304 | SS2S7-1.5-316 | ||
| 2" | 4.062 | 0.065 | SS2S7-2-304 | SS2S7-2-316 | ||
| 2.5" | 5.187 | 0.065 | SS2S7-2.5-304 | SS2S7-2.5-316 | ||
| 3" | 6.312 | 0.065 | SS2S7-3-304 | SS2S7-3-316 | ||
| 4" | 8.312 | 0.083 | SS2S7-4-304 | SS2S7-4-316 | ||
|
SS2WCL-- 90° Buttweld Elbows (1.5 x CLR), Polish ID/OD |
||||||
| Tube OD (Size) |
A | Nominal Wall |
Part Number 304 |
Part Number 316L |
||
| 1/2" | 1.125 | 0.065 | SS2WCL7-0.5-304 | SS2WCL7-0.5-316 | ||
| 3/4" | 1.125 | 0.065 | SS2WCL7-0.75-304 | SS2WCL7-0.75-316 | ||
| 1" | 1.500 | 0.065 | SS2WCL7-1-304 | SS2WCL7-1-316 | ||
| 1.5" | 2.250 | 0.065 | SS2WCL7-1.5-304 | SS2WCL7-1.5-316 | ||
| 2" | 3.000 | 0.065 | SS2WCL7-2-304 | SS2WCL7-2-316 | ||
| 2.5" | 3.750 | 0.065 | SS2WCL7-2.5-304 | SS2WCL7-2.5-316 | ||
| 3" | 4.500 | 0.065 | SS2WCL7-3-304 | SS2WCL7-3-316 | ||
| 4" | 6.000 | 0.083 | SS2WCL7-4-304 | SS2WCL7-4-316 | ||
| 6" | 9.000 | 0.109 | SS2WCL7-6-304 | SS2WCL7-6-316 | ||
| 8" | 12.00 | 0.120 | SS2WCL7-8-304 | SS2WCL7-8-316 | ||
| 10" | 15.00 | 0.120 | SS2WCL7-10-304 | SS2WCL7-10-316 | ||
| 12" | 18.00 | 0.120 | SS2WCL7-12-304 | SS2WCL7-12-316 | ||
|
SS2WUL- 180° Buttweld Return Bends, Polish ID/OD |
||||||
| Tube OD (Size) |
A | B | Nominal Wall |
Part Number 304 |
Part Number 316L |
|
| 1" | 3.000 | 2.000 | 0.065 | SS2WUL7-1-304 | SS2WUL7-1-316 | |
| 1.5" | 4.500 | 3.000 | 0.065 | SS2WUL7-1.5-304 | SS2WUL7-1.5-316 | |
| 2" | 6.000 | 4.000 | 0.065 | SS2WUL7-2-304 | SS2WUL7-2-316 | |
| 2.5" | 7.500 | 5.000 | 0.065 | SS2WUL7-2.5-304 | SS2WUL7-2.5-316 | |
| 3" | 9.000 | 6.000 | 0.065 | SS2WUL7-3-304 | SS2WUL7-3-316 | |
| 4" | 12.00 | 8.000 | 0.083 | SS2WUL7-4-304 | SS2WUL7-4-316 | |
|
SS2CM- 90° Clamp x Weld Elbows, Polish ID/OD |
||||||
| Tube OD (Size) |
A | B | Nominal Wall |
Part Number 304 | Part Number 316L | |
| 1" | 2.562 | 2.062 | 0.065 | SS2CM7-1-304 | SS2CM7-1-316 | |
| 1.5" | 3.438 | 2.937 | 0.065 | SS2CM7-1.5-304 | SS2CM7-1.5-316 | |
| 2" | 4.562 | 4.062 | 0.065 | SS2CM7-2-304 | SS2CM7-2-316 | |
| 2.5" | 5.688 | 5.187 | 0.065 | SS2CM7-2.5-304 | SS2CM7-2.5-316 | |
| 3" | 6.812 | 6.312 | 0.065 | SS2CM7-3-304 | SS2CM7-3-316 | |
| 4" | 8.937 | 8.312 | 0.083 | SS2CM7-4-304 | SS2CM7-4-316 | |
|
SS2FP--90° 14PRF + 13H x Weld Elbow, Polish ID/OD Hex Nut/304 |
||||||
| Tube OD (Size) |
A | B | Nominal Wall |
Part Number 304 | Part Number 316L | |
| 1" | 2.843 | 2.062 | 0.065 | SS2FP7-1-304 | SS2FP7-1-316 | |
| 1.5" | 3.656 | 2.937 | 0.065 | SS2FP7-1.5-304 | SS2FP7-1.5-316 | |
| 2" | 4.812 | 4.062 | 0.065 | SS2FP7-2-304 | SS2FP7-2-316 | |
| 2.5" | 6.062 | 5.187 | 0.065 | SS2FP7-2.5-304 | SS2FP7-2.5-316 | |
| 3" | 7.218 | 6.312 | 0.065 | SS2FP7-3-304 | SS2FP7-3-316 | |
| 4" | 9.343 | 8.312 | 0.083 | SS2FP7-4-304 | SS2FP7-4-316 | |
|
SS2T--90° 15TRF x Weld Elbow, Polish ID/OD |
||||||
| Tube OD (Size) |
A | B | Nominal Wall |
Part Number 304 |
Part Number 316L |
|
| 1" | 2.843 | 2.062 | 0.065 | SS2T7-1-304 | SS2T7-1-316 | |
| 1.5" | 3.656 | 2.937 | 0.065 | SS2T7-1.5-304 | SS2T7-1.5-316 | |
| 2" | 4.812 | 4.062 | 0.065 | SS2T7-2-304 | SS2T7-2-316 | |
| 2.5" | 6.062 | 5.187 | 0.065 | SS2T7-2.5-304 | SS2T7-2.5-316 | |
| 3" | 7.218 | 6.312 | 0.065 | SS2T7-3-304 | SS2T7-3-316 | |
| 4" | 9.343 | 8.312 | 0.083 | SS2T7-4-304 | SS2T7-4-316 | |
|
SS2KS-- 45° Buttweld Elbows w/tangent, Polish ID/OD |
||||||
| Tube OD (Size) |
A | Nominal Wall |
Part Number 304 |
Part Number 316L |
||
| 1/2" | 2.250 | 0.065 | SS2KS7-0.5-304 | SS2KS7-0.5-316 | ||
| 3/4" | 2.250 | 0.065 | SS2KS7-0.75-304 | SS2KS7-0.75-316 | ||
| 1" | 1.188 | 0.065 | SS2KS7-1-304 | SS2KS7-1-316 | ||
| 1.5" | 1.625 | 0.065 | SS2KS7-1.5-304 | SS2KS7-1.5-316 | ||
| 2" | 2.312 | 0.065 | SS2KS7-2-304 | SS2KS7-2-316 | ||
| 2.5" | 3.000 | 0.065 | SS2KS7-2.5-304 | SS2KS7-2.5-316 | ||
| 3" | 3.688 | 0.065 | SS2KS7-3-304 | SS2KS7-3-316 | ||
| 4" | 4.812 | 0.083 | SS2KS7-4-304 | SS2KS7-4-316 | ||
|
SS2WK-- 45° Buttweld Elbows, less tangent, Polish ID/OD |
||||||
| Tube OD (Size) |
A | R | Nominal Wall |
Part Number 304 |
Part Number 316L |
|
| 1/2" | 0.518 | 1.125 | 0.065 | SS2WK7-0.5-304 | SS2WK7-0.5-316 | |
| 3/4" | 0.466 | 1.125 | 0.065 | SS2WK7-0.75-304 | SS2WK7-0.75-316 | |
| 1" | 0.625 | 1.500 | 0.065 | SS2WK7-1-304 | SS2WK7-1-316 | |
| 1.5" | 0.937 | 2.250 | 0.065 | SS2WK7-1.5-304 | SS2WK7-1.5-316 | |
| 2" | 1.250 | 3.000 | 0.065 | SS2WK7-2-304 | SS2WK7-2-316 | |
| 2.5" | 1.562 | 3.750 | 0.065 | SS2WK7-2.5-304 | SS2WK7-2.5-316 | |
| 3" | 1.875 | 4.500 | 0.065 | SS2WK7-3-304 | SS2WK7-3-316 | |
| 4" | 2.500 | 6.000 | 0.083 | SS2WK7-4-304 | SS2WK7-4-316 | |
| 6" | 3.750 | 12.000 | 0.109 | SS2WK7-6-304 | SS2WK7-6-316 | |
| 8" | 5.000 | 16.000 | 0.120 | SS2WK7-8-304 | SS2WK7-8-316 | |
| 10" | 6.250 | 20.000 | 0.120 | SS2WK7-10-304 | SS2WK7-10-316 | |
| 12" | 7.500 | 24.000 | 0.120 | SS2WK7-12-304 | SS2WK7-12-316 | |
