URiSCAN Optima -Semi-Automatic Urine Analyzer
Easy access to review test results (printout data selectable). Interface for the external barcode reader, PC and lab network system; Easy connect by 2 USB port. Reflection photometer :CCD color image sensor (image capture) and 3 LED for light source. Color and clarity reading available. 1.3" Touch Screen TFT LCD; Sofrware available in English, German, Spanish, Italian, Ploish, Chinese and Russian. Memory capacity: 2,000 test results; Simple calibration; asy data management & various; data printing format; Workable with 4-11 parameter strips.
Operation mode: Semi-automatic urine analyzer
Materials: ABS Resin
Dimension: 200mm(M) × 240mm(D) × 90mm(H)
Weight: 970g
Rated voltage: 100 ~ 240V
Rated frequency: 50/60Hz
Rated power: 42VA
Operating conditions: Temperature : 10? ~ 40?(50? ~ 104?); Humidity : 10%~70%
Storage conditions: Temperature : 0?~40?(32? ~ 104?); Humidity : 10%~85%
Measurement method type: Reflectance photometers
Measurement Cycle: Routine mode : 100 seconds; Quick mode : 6 seconds
Memory capacity: 2000 Patient data
Sensor: CCD color image sensor
Light Source: LED
Result Display: 4.3" TFT LCD
Printer: High speed thermal printer 203 dpi (8dots/mm)
Host-communication: Bi directional RS 232C interface for data transfer to HOST
Peripherals: Barcode reader, External printer
Safety stadard: EN / IEC 61010-1
EMC standard: Emission EN55011/A1 : 1997,A2:1996, Group 1, Class A immunity EN 61000-4-/3/4/5/6//11
Approval: CE, FDA
