MagicTouch - Model SCB - Sirolimus Drug Coated Balloon Catheter
Novel, First of its kind Sirolimus drug coated balloon catheter for the treatment coronary artery disease. MagicTouch is intended for in-stent restenosis, small vessels, bifurcation lesions and de-novo lesions
TECHNOLOGY
An innovative proprietary Nanolute technology providing better bioavailability of SIROLIMUS
COATING
Unique coating technology leads to 100% balloon surface coating
DRUG
Sirolimus: A drug with proven safety profile
CARRIER
A biocompatible phospholipid drug carrier improving the adhesion property of Sirolimus
NANOLUTE TECHNOLOGY is designed to improve the lipophilicity and bioavailability of Sirolimus
- Phospholipid is a drug carrier with two lipophilic tails and one hydrophilic head.
- Sirolimus is encapsulated in phospholipid with proprietary Nanolute technology.
DRUG/EXCIPIENT
Drug: Sirolimus
Drug Dose: 1.27µg/mm²
Drug Carrier: Phospholipid Based Excipient
Balloon
Balloon Material: Polyamide
Catheter design: Rapid Exchange(RX) Design
Delivery system
Shaft Diameter – Proximal: 1.7 F
Shaft Diameter – Distal: 2.5 F
Usable Catheter Length: 140 cm
Tip Profile: 0.016”
Nominal Pressure: 6 bar
Rated Burst Pressure: 16 bar (14 bar for 4.00/ 25 to 40 mm)
Guiding Catheter Compatibility: 5F
Guidewire Compatibility: 0.014” maximum recommended
