WPI Classic -Model EZ-7000 -Small Animal Anesthesia System
EZ Anesthesia is the system of choice for anesthetizing small animals, and it comes with a variety of choices. Animals to be anesthetized are placed in the acrylic induction chamber, and the system delivers a precisely blended mixture of oxygen and isoflurane. An activated charcoal air filter canister at the top of the chamber releases safe, filtered air back into the room. A water-heated cage warmer or warming plate (ATC2000) is used to retain the animal body temperature while in the induction chamber. After the initial anesthetizing, the animal may be moved to the heated surgical water bed and positioned properly in the snugly fitted nose cone. A highly sensitive valve regulated by the animal’s breathing works with the nose cone to ensure non-rebreathing efficiency. It allows safe anesthesia for up to several hours.
Complete small animal anesthesia system and all the accessories
- Safe for surgical personnel, 90% below OSHA Isoflurane limit
- Time efficient and cost-effective
- Virtually stress free for the animals
- Speedy recovery time
- Inhalation anesthesia (quick induction, speedy recovery and minimal animal handling)
- Effective for neonates up to 1 kg animals
The breathing device also includes an air filter that releases safe, filtered air back into the room.
Oxygen and liquid isoflurane are not supplied. These are required to operate the system. Each system comes with all necessary components and connections for immediate use, including:
- Oxygen Regulator
- Vaporizer Unit
- One Induction Chamber (standard EZ-178)
- One Breathing Device (standard EZ-103)
- Case of Charcoal Filters
- Connecting tubing
Other available options include:
- Heated water beds
- Additional Breathing Devices
- Chambers in a variety of sizes
- Key fill isoflurane vaporizer is available separately or may be substituted in a complete system (Call for details)
- Small animal surgery
- Compact and portable
- Easy to setup and use, simplifying the training of new staff and reducing the threat of human error
- Turnkey (Alll-in-one) system or plug and play system
EZ-7000 System Comes Standard With:
- EZ-150C Classic Vaporizer Unit
- EZ-103A Microflex Mouse/Rat Non-Rebreathing Device
- EZ-178 Mouse/Rat Sure-Seal Induction Chamber
- EZ-258 Charcoal Filters (8)
- EZ-320 Oxygen Regulator for ‘H’ Tanks
- Also includes mouse/rat nosecones, nosecone plugs, plastic surgery beds (2) and all connecting tubes
Options Include:
- Oxygen Regulation
- Heated Surgical Beds
- Size of Induction Chamber
- Type and Number of Non-Rebreathing Devices
