Binder -Model ELC, Series 570 -Snap-In Male Cable Connector
Snap-In Male cable connector, Contacts: 12, 4.0-6.0 mm, unshielded, solder, IP54.
Most popular related searches
- Connector design : Male cable connector
- Version : Connector pin straight
- Connector locking system : snap-in
- Termination : solder
- Degree of protection : IP54
- Cross-sectional area : max. 0.25 mm² / AWG 24
- Cable outlet : 4.0-6.0 mm
- Temperature range from/to : -25 °C / 85 °C
- Mechanical operation : > 5000 Mating cycles
- Weight (g) : 17.43
- Customs tariff number : 85369010
- Country of Origin : DE
- Rated voltage : 150 V
- Rated impulse voltage : 1500 V
- Rated current : 2.0 A
- Insulation resistance : ≥ 1010 Ω
- Pollution degree : 2
- Overvoltage category : II
- Insulating material group : II
- EMC compliance : unshielded
- Housing material : PA
- Contact body material : PA
- Contact material : CuZn (brass)
- Contact plating : Au (gold)
- REACH SVHC : CAS 7439-92-1 (Lead)
- SCIP number : d7aef40e-41cc-4e80-9aea-62cc045796c7
