ILO -Model EcoCAM 750 -Standard Camera. Basic 1CCD
Camera head: Aspect ratio: 4:3. Image sensor: 1/3`` CCD. Immersible (using the attached cap).
Most popular related searches
- Voltage range (current consumption): 100-240 V (25 VA)
- Frequency: 50-60 Hz
- Device protection: 2x T3,15 A
- Video System: PAL/NTSC
- Image resolution: PAL 752 x 582/ NTSC 768 x 494
- TV resolution: > 470 lines
- Sensitivity: < 1 lux (1/1.4)
- White balance automatically, with data hold shutter speed PAL (NTSC): 1/50 (1/60) to 1/100.000 sec
- Video out terminal 2x Video; 2x S-Video; 1x Y-Pb-Pr (Component); 1x SDI; 1x USB 2.0
- Protection class (acc.to IEC 60601-1): I
- Safety class: BF
- IP code: 20
- Standard: IEC 60601-1-2
- Device classification (acc. to MDD 93/42/EEC): I
- Dimensions (WxHxD): 355mm x 103mm x 253mm
- Weight: approx. 4,4 kg
- Delivery contains:
- CCU, camera head with 3,05m (10ft) cable, mains cable,
- User manual, Y/C cable, BNC cable
