Model US 100 - US 200 - Steelco Surgical Instrument Ultrasonic Cleaning
This Ultrasonic Cleaning System combines a stainless steel cleaning tank with industrial style transducers and a powerful ultrasonic generator to provide the strongest tabletop cleaning available. It gives the speed and effectiveness of ultrasonic cleaning power with the convenience of plug-in-anywhere operation. A DIN tray basket support and cover are included in the base unit. It meets CSA and UL requirements. The large capacity of this model assures consistently tested and efficient washing performances reaching, at the same time, increasing reprocessing needs. Critical process parameters such as temperature, ultrasonic power and time are monitored granting the compliance to the international standards and can be recorded.
Tank dimensions: 600x350x345h mm 23.62”x13.78”x13.58”
Basket capacity: nr. 3 DIN 1/1 net baskets each tank
Luer lock connections: nr. 12 each tank
Washing tank made of stainless steel AISI 316L
External body made of stainless steel AISI 304
LED display and timer for cycle control
Automatic tank filling and water control level
Pump for the automatic chemical dosing
Automatic minimum level of chemical control with alarm
Ultrasonic power control from 0 to 100%
Radio frequency interference filter
Models:
US 100: automatic module with 1 ultrasonic tank
US 200/1: automatic module with 1 ultrasonic tank
US 200/2: automatic module with 2 ultrasonic tanks
US 200/3: automatic module with 1 ultrasonic and 1 rinsing tank
The rinsing tank of US 200/3 model can be equipped with a filtered hot air dirying system.
