Labtech - Model EC-12H - Twelve-Channel, Full Disclosure Holter Recorder
FromLabtech Ltd.
Additional Recorder for ECG Holter System. Twelve-channel, full disclosure Holter Recorder for an earlier purchased Holter System. With Labtech EC-12H Holter Recorder you can make 1, 2, 3 or 12 channel recordings depending on the recorder and patient cable type being used.
Most popular related searches
- Parameters: EC-12H
- Bipolar ECG Channels: 1, 2, 3, 12
- Other ECG Channels: +PM, Nehb, Standard 12 CH, Nehb
- Respiration:Yes
- Patient cables for recording:
- 1, 2, 3 and 12 channels
- Number of snap type Leads: 3, 4, 5, 7, 10
- Recording duration maximum (without battery changing): 24h
- The battery can be changed during recording: Yes
- Recording duration maximum (with battery changing): 336h
- Dynamic Bandwidth: ±20 mV
- DC Offset Range: ±600 mV
- Frequency Response maximum: 0.05 Hz … 150Hz
- Sampling Rate: 125 Hz, 250 Hz, 500 Hz, 1000 Hz
- Recording Rate: 125 Hz, 250 Hz, 500 Hz, 1000 Hz
- Common Mode Rejection Ratio: 120dB
- A/D Resolution: 16 bit
- Input impedance: >100 MΩ
- Power Source: 1x1.2 V AAA NiMH battery
- (or 1x1.5 V AAA alkaline battery)
- Battery Life: min. 24 h, up to 48 h using a high-capacity battery
- Storage Card Capacity: built-in 2GB (microSD)
- Internal Voltage (max): 3.3 V
- Display: LCD (Grey Scale 160x100 pixels)
- Movement detection-3D: Yes
- Patient Event button: Yes
- Monitoring ECG: On PC via Bluetooth and on LCD as well
- Reading Record: via USB cable
- International Protection Rating Against Water: IPX0
- Size: 53 x 67.5 x 18.5 mm
- Weight: ~ 50 g
