Ultra-Compact Proton Cancer Therapy System
We are trying to overturn the image that society has of radiotherapy and proton therapy with our innovative technology. We are developing proton therapy with the hope of making it accessible to all cancer patients.
Compact design fitted in an existing
Compact Designa
A rotating gantry equipped with a huge magnet has been required to irradiate the proton beam from multiple directions to the patient. We have developed a revolutionary technology that changes the beam angle without rotating a huge gantry, and realized miniaturization.
A gantry without a large rotating mechanis
Magnet Design
Significant miniaturization has been achieved by patented magnet design without requiring a large rotating mechanism, a non-rotating gantry. That realizes the isocentric irradiation technique with a kicker magnet and a superconducting magnet as a bending magnet, the magnetic field of which was optimized. Patent No. 6364141,6387476
Scanning irradiation supporting a moving organ
Scanning Irradiation
Many organs that are expected to be effective for proton therapy move with breathing (e.g. lungs, liver, pancreas). The combination of respiratory-gated irradiation method and high-speed scanning method also supports irradiation of moving organs.
Gantry and treatment table for high degree of freedom of treatment
Gantry/Al shuttle
It is required to decrease radiation doses in surrounding healthy tissues for lesions with a complicated structure. Highly conformal dose distribution to the target can be achieved with multiple directions beam.
