Mcube -Model BioCon-1100 -Ultrasonic Bladder Volume Measurement System
The 3D-Mecanical Sector Transducer captures the bladder in 12 sections and calculates the volume of the bladder based on the images.
Most popular related searches
bladder volume measurement
bladder volume
bladder volume measurement system
bladder scanning
patient identification
The BioCon-1100 measures bladder volume non-invasively with ultrasound.
Display: Color Touchscreen
10.1 inch (Wide SVGA)
Volume Range: 0-999ml
Accuracy : ±7.5ml (0-99ml) ±7.5% (100-999ml)
Scan Time: Approximately 2 seconds
Ultrasound Probe:
Dual frequency (2.8 MHz, 3.7MHz)
B-mode scan image
Scan angle: 120°
Penetration depth: 23cm
Probe: IPX5: Probe: IPX5
Patient ID input: Patient ID input
Interface: Wi-Fi Direct Barcode Reader
Printer: Built in Thermal Printer
Power: Rechargeable Li-ion battery
Voltage: 7.26V Capacity: 5200mAh
Charging time: approximately 4 hours
Approximately 1000 scans available
OS: Linux
