Ability Engineering Technology, Inc.
About

AET - Vacuum Insulated Piping

SHARE

AET Designs and Manufactures vacuum jacketed transfer lines for the cryogenic industry. This application is utilized to transfer gases/liquids with a low boiling point while shielding them from atmospheric interference. These piping assemblies can also include Flex Segments to help with customer connection point alignment.Transferring cryogenic liquid without vacuum jacketing can cost a large amount of money due to heat leaks. Keeping waste costs down can mean more funding for other parts of your project, or in some cases, more end product to sell to your end user.

Most popular related searches
cryogenic liquid
cryogenic storage
cryogenic vacuum
cryogenic system

These assemblies are commonly used for:

  • Thermal Expansion/Contraction Relief
  • Slight Alignment Control

Advantages to AET Flexible Assemblies:

  • Large Range of Flex Diameters
  • Multiple End Connection Choices
  • With or Without Braid (Dependent on Design Pressure)
  • Material Certifications Available Upon Request
More Info:
Vacuum Jacketed Pipe (AKA Vacuum Insulated Pipe or Cryogenic Piping) is utilized in systems that require the transfer of low boiling point liquids from point “A” to “B”. The diagram below is a typical example of a cut-through vacuum jacketed pipe segment. The inner pipe or tube contains the process medium and is insulated with multiple layers of mylar-based insulation. There are low-heat leak spacers placed between the inner and outer tubes to keep them separated to avoid heat leaks via metal to metal transfer. The outer pipe would be fit with a pumpout port to remove air from the anular space and thus create a vacuum insulating area.

Below is a list of tools and resources related to vacuum jacketed lines.

  • Cryogenic Society of America is a not-for-profit organization that provides information and resources for all things in the Cryogenic industry, as well as organizing their quarterly issue of “Cold Facts” magazine to those interested.
  • ASME B31.3 is a guideline for piping safety and has been adopted into many vacuum jacketed pipeline designs. The guidelines there-in outline many things, but a table of contents page can be seen at the reference link.

Some applications that would benefit from vacuum jacketed transfer lines include:

  • Testing Centers
  • Liquid Natural Gas Relocation
  • Cryogenic Storage
  • Cryo Transfer Systems
  • Helium Purification Systems
  • Food Industry
  • Low Boiling Point Liquid Transfer
