The Vadzo Bolt-1335CRS is a 4K MIPI camera that leverages the Onsemi AR1335 CMOS Sensor, equipped with a high-performance image signal processor (ISP). It captures images at a maximum resolution of 13MP with a pixel size of 1.1 µm by 1.1 µm and supports video streaming in 4K, 1080p, and 720p formats. This camera is ideal for applications in retail AI, facial recognition, kiosks, and digital signage. It is engineered for integration with platforms such as Raspberry Pi, Nvidia Nano, and Nvidia XavierNX. The camera is compatible with 2 Lane MIPI CSI-2 and 4 Lane MIPI CSI-2 interfaces and features an S Mount (M12 Standard) optics with a 74-degree field of view. With dimensions of 38mm by 38mm transformable to 32mm by 32mm, it operates in temperatures ranging from -30°C to 70°C, ensuring robust functionality across various environments.

The Vadzo Falcon-1335CRS is an advanced 4K USB 3.0 camera featuring the Onsemi AR1335 CMOS sensor, optimized for applications requiring high-resolution imaging and video streaming capabilities. With a maximum resolution of 13 megapixels and support for 4K, 1080p, and 720p video outputs, this camera is ideally suited for integration into various systems such as kiosks, digital signage, facial recognition setups, and medical imaging devices. Its rolling shutter and S mount (M12) optics ensure efficient image capture, while the USB 3.0 Gen1 Type C interface offers backward compatibility with USB 2.0, facilitating easy connectivity and power management. Operating effectively within the temperature range of -30°C to 70°C, and weighing just 13 grams without the lens, the Falcon-1335CRS is a versatile component for diverse imaging solutions. UVC compliance and compatibility with Windows, Linux, and Android systems further enhance its adaptability for custom applications.

The Vadzo Merlin-291CRS is a sophisticated low-light USB 2.0 camera designed with the advanced IMX291 Sony Starvis Sensor, accompanied by a high-performance Image Signal Processor (ISP). It achieves a maximum resolution of 2 megapixels, supporting video streaming at 1080p and 720p, making it ideal for various technological applications. These include uses in kiosk cameras, digital signage, retail AI, medical devices, and facial recognition technologies. Engineered to operate efficiently in low-light conditions, this camera leverages its rolling shutter capability and a sensor format of 1/2.8 inches with a pixel size of 2.9 µm x 2.9 µm. It supports Windows, Linux, and Android operating systems with an additional SDK requirement. The camera's robust features include a USB 2.0 Micro B interface, providing reliable connectivity, while ensuring conformity to UVC compliance standards alongside RoHS 3 and REACH. Compact and lightweight at just 11 grams without a lens, this model offers a flexible and powerful solution to modern imaging challenges.
